WMT Conjugated Cam

Cam Type Rapier Loom offers efficient weaving, precise weft insertion, stable operation, high productivity, versatile fabric production, and consistent quality.

View Specifications Machine Models
WMT Conjugated Cam
Product Overview

Built for high-speed, heavy-duty shedding.

The WMT Conjugated Cam range combines a conjugate CAM, positive double-lift and fully-open shedding mechanism with module-based selection and an embedded intelligent control system.

600RPM maximum speed
45–109mm front shedding range
72–120mm back shedding range
14+WMT model variants
MODEL RANGE

Choose the right WMT configuration.

WMT1408 WMT2816 WMT3072 WMT3072-24 WMT5120 WMT5376 WMT5376-24 WMT6144 WMT6912 WMT8448 WMT10240 WMT12288 WMT13312 WMT14336
Technical Specification

WMT Conjugated Cam at a glance

Speed Up to 600 RPM
Selection Model Module + drive circuit board + aluminum alloy lifting knife
Shedding Form Conjugate CAM, positive double-lift, fully-open shedding mechanism
Front Shedding Height 45–109 mm, with easy adjustment
Back Shedding Height 72–120 mm, with easy adjustment
Application High-speed rapier, air jet, water jet and projectile looms
Suitable Fabrics Trademark, tie, garment fabric, decorative fabric, shawl, towel, tapestry and other heavy-duty designs
Control Embedded intelligent control module and touch-screen human-computer interaction interface
Drive Customized servo or motor; synchronous drive with looms without vertical shaft
